Briquette Press Manufacturer
Jay Khodiyar Machine Tools manufactures high-performance Biomass Briquette Press designed to convert agricultural, forestry, and industrial biomass waste into dense, uniform fuel briquettes. Our JK 90 Briquettes Press provides an efficient and sustainable solution for producing renewable fuel as an alternative to conventional fossil fuels.
The machine is suitable for a wide range of raw materials, including sawdust, wood waste, rice husk, sugarcane bagasse, groundnut shells, cotton stalks, and other biomass residues. With high-pressure compaction of up to 2000 kg/cm², it produces strong, durable briquettes without chemical binders, utilizing the natural lignin in biomass as the binding agent.
Built for high productivity, reliable operation, and long service life, the JK 90 helps transform waste biomass into valuable, high-density solid fuel for industrial boilers, heating systems, and biomass energy applications.
Technical Specifications
Advantages of Briquette Press
The mechanical briquette press develops a compression force of approximately 2000 kg/cm Bar to obtain a high quality briquette of a high density and a remarkably reduced volume, without the addition of binders.
Technical Specifications
| Parameter | Specification |
|---|---|
| Machine Type | Briquette Press |
| Briquetting Technology | High-Pressure Mechanical Piston Press |
| Briquette Diameter | 65 mm, 75 mm, 90 mm (Model Dependent) |
| Material in feed Size | 1mm x 5mm x 12mm |
| Material Moisture | 8–12% (More than 15% required Drying) |
| Briquette Length | 50mm-450mm |
| Binder Requirement | No Chemical Binder Required (Natural Lignin Acts as Binder) |
| Compression System | Mechanical Ram & Die |
| Lubrication System | Automatic / Centralized Lubrication |
| Construction | Heavy-Duty Mild Steel Fabrication |
| Drive System | Heavy-Duty Electric Motor with Flywheel |
| Feeding System | Screw Feeder with Hopper |
| Operating System | Electrical Control Panel |
| Safety Control | |
| Auto cut-off system | |
| Maintenance | Low Maintenance with Easy Access to Wear Parts |
| Operation | Continuous Industrial Operation (24×7) |
| Applications | Industrial Boilers, Furnaces, Brick Kilns, Steam Generation, Biomass Power Plants, Thermal Heating Systems |
Raw Materials
Forest Waste: Sawdust, sander dust, wood chips, tree bark, bamboo waste, veneer waste, and other forestry residues.
Agricultural Waste: Rice husk, groundnut shells, coconut shells, cotton stalks, sugarcane trash, wheat straw, paddy straw, maize waste, corn cobs, and other crop residues.
Industrial & Municipal Waste: Paper waste, bagasse, RDF, municipal solid waste (MSW), and other combustible waste.
We offer a complete range of briquetting machines in various capacities and configurations to suit different raw materials, production requirements, and industrial applications.
How to Produce briquettes
- Raw Material Collection – Collect agricultural, forestry, and industrial biomass waste.
- Crushing – Reduce the material to the required size using chippers, shredders, or hammer mills.
- Drying – Lower the moisture content to 8–12% using flash or rotary dryers.
- Briquetting – Compress the material under high pressure to form dense briquettes using natural lignin as a binder.
- Shaping & Cooling – Shape the briquettes and cool them to enhance strength and durability.
- Packaging – Pack the finished briquettes or supply them in bulk for industrial use.
Standard Models (Typical)
| Model | Briquette Size | Power | Production Capacity* |
|---|---|---|---|
| JK-65 | 65 mm | 59 HP | 500–700 kg/hr |
| JK-75 | 75 mm | 69 HP | 700–1000 kg/hr |
| JK-90 | 90 mm | 91 HP | 1000–2,000 kg/hr |
Note: Production capacity depends on the type of biomass, bulk density, moisture content (recommended 8–12%), particle size, and machine configuration. Custom briquetting plants can be designed to meet specific production requirements.
